Access is a design decision, not an afterthought

On a golf course project, the routes machines take are as much a part of the design as the greens and tees. Get them right and the build runs smoothly, turf recovers quickly and nobody gets hurt. Get them wrong and you spend the following season repairing ruts, rebuilding drainage and explaining to members why the fourth fairway looks like a building site.

The time to plan access is at the drawing board, alongside the shaping plan and the irrigation layout. By the time the first excavator arrives, the haul roads, turning areas and crossing points should already be pegged, priced and agreed with the contractor.

Start with a proper site survey

Before you mark a single route, you need to know what the ground can take. A walkover with the contractor, the shaper and the ecologist is worth more than any number of plan-view sketches.

• Soils and drainage: heavy clay holds water and turns to slurry under a loaded dumper. Sandy or chalky ground drains fast but scours easily. Both need different surfacing.
• Gradients: anything over about 1 in 8 becomes difficult for wheeled machines and dangerous when wet. Tracked machines cope better but chew the surface.
• Existing features: mature trees, watercourses, ditches, gas and water mains, and any protected habitat. Root protection areas should be marked and fenced, not just noted.
• Ground conditions after rain: visit the site in February, not just July. What looks firm in summer can be impassable after a week of Welsh or Scottish rain.

Designing temporary haul roads that actually work

A haul road is a temporary structure, but it must be built to permanent standards if it is to protect the ground beneath. The usual approach in the UK is a geotextile separation layer topped with a compacted granular sub-base, typically Type 1 or a recycled equivalent.

Think about the loads. A 13-tonne tracked excavator, a loaded 9-tonne dumper and a delivery lorry carrying bentgrass turf all impose very different pressures. Width matters too: a single-track route forces machines to run on the verges, which is exactly where damage starts. Two-lane running, or a well-spaced one-way system, keeps traffic off the soil.

• Use a minimum running width of 3.5 to 4 metres for two-way plant movement.
• Increase sub-base depth at soft spots rather than spreading it thinly everywhere.
• Build in a slight camber and side drains so the road sheds water instead of holding it.
• Lay bog mats or steel tracking over short wet sections rather than excavating them out.

Where a route must cross a fairway or a green surround, consider a temporary bridge or a reinforced crossing point. It is cheaper than reconstructing a rootzone in September.

Turning areas, passing places and visibility

Machines need room to manoeuvre, and the places they turn are usually the places that suffer most. Design dedicated turning circles at the ends of haul roads, near soil stockpiles and at material drop-off points.

Articulated dumpers need a turning radius of around 8 to 10 metres when loaded. Tracked excavators can spin on the spot, but a 360-degree slew over turf leaves a scar that takes months to grow out. A gravel pad or a matted area solves both problems.

Passing places matter on longer routes. Space them every 100 to 150 metres, with clear sightlines so drivers can see oncoming traffic. On bends and at site entrances, a banksman or a simple one-way system is far safer than hoping two drivers spot each other in time.

Protecting turf, trees and drainage as you go

Access routes should avoid the best turf, but some crossing is inevitable. Where it happens, plan it deliberately.

• Strip and stockpile turf from any route that will be buried under stone, and keep it damp and shaded.
• Keep soil heaps to a sensible height, no more than about two metres, to avoid compaction and loss of structure.
• Install silt traps and check dams on any drainage outfall that receives runoff from haul roads.
• Use a wheel wash or a stone apron at the site entrance to keep mud off the public road.
• Fence root protection areas before plant arrives, and route around them rather than through them.

Dust is often overlooked. On dry summer days, a bowser or a sprinkler on the haul road keeps dust down and protects nearby greens from a fine coating of stone.

Phasing, reinstatement and the final handover

Access routes should follow the construction sequence, not fight it. If the irrigation main is going in first, the haul road may need to move twice. A phased plan, agreed in writing with the contractor, avoids a situation where a finished green is the only way to reach the eighteenth tee.

Build reinstatement into the programme and the budget from day one. That means removing stone, decompacting subsoil, replacing topsoil and turf, and allowing a full growing season where possible. A route restored in October may look acceptable by the following June, but only if it was planned for.

The best compliment a finished course can receive is that nobody can tell where the machines went. That happens when access is designed with the same care as the golf itself.
